Side Tilt Carriage - There are actually 4 sizes of hook type blade carriages rated by the blade carriage hoisting capability. Hook type blade carriages have been the same.
Class I carriages are rated for loads up to 2000 lbs. The carriage bar spacing utilized for Class I is thirteen inches. Class II carriages are rated for cargo up to 5,550 lbs. Their carriage bar spacing is 16 inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this particular class is 20 inches. Class IV carriages are rated for loads up to 15,500 lbs. The carriage bar spacing utilized for this capacity is 25 inches.
Pin mounted blades vary by the amount of offset between the tine and the fork eye. Various manufacturers would differ the carriages for pin type blades. Carriage capacity will be established by the carriage pin size and by the fork size.
